450 SX-F 2024

450 SX-F 2024

Description

We aren't ones to brag, but with a trophy cabinet ready to rip at the seams, the KTM 450 SX-F is the epitome of a podium hunter. With 5 AMA 450 supercross titles in the last 7 seasons, the 2024 KTM 450 SX-F rolls into the paddock already armed with the learnings of past championships. It's time to extend the trophy room.

Specification

Transmission 5-speed
Starter Electric starter
Stroke 63.4 mm
Bore 95 mm
Clutch Wet, DDS multi-disc clutch, Brembo hydraulics
Displacement 449.9 cm³
EMS Keihin EMS
Design 1-cylinder, 4-stroke engine
Lubrication Forced oil lubrication with 2 oil pumps
Battery capacity 2 Ah
Battery voltage 12.8 V
Cylinder count 1
Fuel-mixture generation Keihin EFI, throttle body 44 mm
Cooling Liquid cooled
Valve timing 4 V / SOHC with rocker arms
Cycle 4-stroke
Rear subframe design Aluminum-reinforced polyamide
Tank capacity 7.2 l
Front brake disc diameter 260 mm
Rear brake disc diameter 220 mm
Front brake Disc brake
Rear brake Disc brake
Chain 520, Non-sealed
Frame design Central double-cradle-type 25CrMo4 steel
Front suspension WP XACT-USD, Ø 48 mm
Rear suspension WP XACT Monoshock with linkage
Steering head angle 63.9 °
Ground clearance 359 mm
Seat height 958 mm
Suspension travel (front) 310 mm
Suspension travel (rear) 300 mm
Fork offset 22 mm
Weight (ready to race) 102.6 kg
Handlebar Neken, aluminium Ø 28/22 mm
Wheels Spoked wheels with aluminium rims
Tyre width (rear) 110
Tyre width (front) 80
Silencer Aluminium
Orange
